US Motors U2S2ACR General Purpose AC Motor – 2 HP, 1725 RPM, 208-230/460V, 3-Phase, TEFC, 145TC Frame

Brand
U.S. ELECTRICAL MOTORS

Model
U2S2ACR

Type
Motors, A.C.

Stock #
LMAC1766-002

Condition
New

Year
Not Specified

Location
PORT CARBON, Pennsylvania
United States

Price

$199.99

Request a Quote

Specifications

Equipped With

For sale is a US Motors General Purpose AC Motor, model U2S2ACR, designed for reliable performance in various industrial and commercial applications. This motor is in good working condition and features the following specifications:

Model Number: U2S2ACR
Serial Number: P117390016-0057M0015
Horsepower: 2 HP
Speed: 1725 RPM
Voltage: 208-230/460V (60 Hz); 190/380V (50 Hz)
Amperage: 5.8-5.4/2.7 A (60 Hz); 6.4/3.2 A (50 Hz)
Frequency: 60 Hz / 50 Hz
Phase: 3-Phase
Frame: 145TC
Enclosure: Totally Enclosed Fan Cooled (TEFC)
Mounting: C-Face with Foot
